Product Advantages
◆ Food grade oil, non-toxic, tasteless, clean, smooth.
◆ Stable high and low temperature performance, high lubricity; Compliance with FDA and NSF.
◆ Meet the American NSF food grade H-1 standard: European Union ROHS and REACH
environmental standards.
Product Features
| Test items | BX-120/0(D) | BX-120/2(D) | BX-120/3(D) | Test Methods |
| Color | white | white | white | IP196 |
| Base oil | Refined mineral oil | Refined mineral oil | Refined mineral oil |
|
| Base oil viscosity at 40℃ | 32cst | 32cst | 32cst |
|
| Thickener | Lithium | Lithium | Lithium |
|
| Penetration | 355-385 | 265-295 | 220-250 | GB/T 269 |
| Consistency value (NLGI) | 0 | 2 | 3 | The data is the max operating temperature. The actual data is depend on the test result. |
| Working temperature℃ | -25℃ to +130℃ | -25℃ to +130℃ | -25℃ to +130℃ |
|
| Drop point℃ | 165℃ | 180℃ | 180℃ | GB/T 3498 |
| Copper corrosion (100 ℃ / 24Hrs) | qualified | qualified | qualified | GB/T 7326 |
| Four ball test (40kg/1 Hr/1200rpm/75℃) | 250KG | 250KG | 250KG | GB/T 0202 |
Product Usage
Small motor and shaft rod, shaft lubrication.
Lubrication of toys, audio-visual equipment and home appliances.
All kinds of automation equipment lead rod, guide rail, movable rod, CAM, low speed bearing lubrication at room temperature.
All kinds of different parts of the activity lubrication.
Standard models: BX-120/0(D), BX-120/2(D), BX-120/3(D)
Packing specification: 15KG (plastic barrel)，170KG (plastic barrel) Customized according to customer requirements.
